Bulgin Circular Connector, 9 Contacts, Cable Mount, Plug, Male, IP68,

Name: Bulgin Circular Connector, 9 Contacts, Cable Mount, Plug, Male, IP68,
Brand: Bulgin

Bulgin Circular Connector The Bulgin Buccaneer series 9-poles male circular flex cable connector has a plug-type connection. This connector has a voltage rating of 150VAC/DC and current rating is up to 5A per contact. This cable mounting connector is ideal for use in challenging conditions. The connector shell is made from glass-filled polyamide with gold-plated copper alloy contacts. The connectors also feature a positive locking mating system that means the connector cannot be mismatched. Environment The standard series of buccaneer connectors are protected to IP68 when mated. This means they are dust-tight and resistant to particle ingress such as dust and sand. They are also waterproof, meaning they are protected from liquid ingress up to the point of submersion for a limited time. Frequently asked questions (FAQs)Q: Are there accessories available for this connector? A: There are connector caps available for standard buccaneer connectors, which maintain the IP68 sealing when mated pairs are uncoupled. The cap can also be used as a tool to aid the removal and refitting of inserts during assembly. Q: How durable is the connector? A: The standard buccaneer series of power connectors feature glass filled polyamide moulded housing that is resistant to dust, oils and saltwater. Q: What are the mating requirements of this connector? A: The Buccaneer standard series cable connectors mate with corresponding in-line connectors for a cable-to-cable connection, or with a panel, chassis and PCB connectors. Q: Are contacts supplied with this connector? A: The connector comes complete with contacts. Features and Benefits Crimp termination Straight body orientation Cable acceptance ranges between 6mm and 8mm Easy assembly, no special tools required Insulation resistance is greater than 104Mohm Operation temperature ranges between -20°C and 70°C Positive locking keyways Unshielded Water and dustproof Applications Electrical equipment Industrial automation Certifications CSA certified IP68 rated UL approved VDE approved Approvals CSA; UL; VDEVis mere
