Ecler CA120HZ Micro Amplifier, 96W Mono, 70V and 100V Line, Fanless, RS-232 Control

Name: Ecler CA120HZ Micro Amplifier, 96W Mono, 70V and 100V Line, Fanless, RS-232 Control
Brand: Ecler

The Ecler CA120HZ is the 70V/100V line version of the CA120 micro amplifier, giving a single mono output of 96W for driving many ceiling or wall speakers over long cable runs. It has a microphone/line input, two stereo line inputs summed to mono, tone controls, and control by IR remote, 0 to 10V Ecler wall panel or RS-232. Typical uses are classrooms, shops, cafés, offices and corridors. 96WAt 100V70/100VLine outputRS-232Control portFanlessCooling Mounting and powerPowered by an external universal 24V DC supply. Designed to sit on a wall or under a shelf, table or cupboard rather than in a rack. Output powerEcler's rated output for this model is 96W at 100V (100 ohm load). The output is mono only: stereo sources are summed. Features1x 96W mono output for 70V or 100V speaker lines, with 50 Hz or 70 Hz high-pass filter1 microphone/line input (balanced Euroblock or jack) with phantom power, noise gate and talkover priority2 unbalanced stereo line inputs on minijack or dual RCABass and treble controlsAuxiliary line output for linking to another amplifierRotary encoder for local control, IR remote control supplied0 to 10V remote port for Ecler WPaVOL or WPaVOL-SR wall panels (volume and input or preset selection)RS-232 port for EclerCOMM software and the CA-NET protocolMute input triggered by a dry contact, for example from a fire alarm systemAuto standby after 120 seconds without signal; fanless convection cooling SpecificationsOutput power (1% THD)96W at 100V (100 ohm load)OutputMono, 70V or 100V line; L+R summedHigh-pass filter50 Hz or 70 HzInputs1 mic/line (balanced Euroblock or jack), 2 stereo line (minijack or dual RCA)Input sensitivityLine: 0 dBV (-6 dBV internally selectable); mic: -20 to -50 dBVInput impedanceLine: >8 kohm; mic: >1 kohmFrequency response50 Hz to 30 kHz (-3 dB)THD+NSpeaker out: 50 dBControlIR remote, 0 to 10V remote port, RS-232, mute contactPowerExternal 24V DC supply, 100 to 240V ACStandby consumptionShow more

from £463.00
