Vici Valco 10 mpos Dead-end Flow Path Selector, MW-Valve, manual, 3'' Standoff, 1/16'' Fitting, 0.75 mm Port, 200°C / 400psi, forGas, N60/E

Name: Vici Valco 10 mpos Dead-end Flow Path Selector, MW-Valve, manual, 3'' Standoff, 1/16'' Fitting, 0.75 mm Port, 200°C / 400psi, forGas, N60/E
Brand: Vici Valco

Selectors (multiposition valves) step incrementally through continuous revolutions, instead of switching back and forth like two position valves. (Selectors step bi-directionally with electric and universal actuators.) The preload design allows the rotor to be inspected or replaced without taking the valve off the actuator. Valves ordered with a electric actuator are permanently aligned.Valco selectors are available in five lower pressure flowpaths typically used in gas chromatography applications (most also available with the built-in purge feature), and two high pressure flowpaths suitable for high performance liquid chromatography. SD valves select one of 4 to 16 dead-ended streams, directing it through the valve outlet to a sample valve, pressure sensor, detector, column, etc. The same configuration can also direct one stream to a number of outlets for fraction collection. Manual actuation offers the advantages of simplicity and low cost.Meer tonen

vanaf € 1.998,89
